Description
Zulu Code has not yet published a description for ^PAKE. Contribute one.
Did you know
- The Grundfos MAGNA3 series was introduced to the market in August 2012, with a significant launch at the AHR Expo in 2013. It builds upon Grundfos's decades of experience in electronic pumping and the established MAGNA technology.
- The MAGNA3 series is positioned as Grundfos's premium and most advanced circulator pump, offering extensive control and monitoring capabilities. It sits above the MAGNA1 series, which is designed for more basic performance needs and straightforward control.
- The MAGNA3 is chosen for its ultimate energy efficiency, achieving an Energy Efficiency Index (EEI) as low as 0.18, and its intelligent features like AUTOADAPT and FLOWADAPT, which optimize performance and reduce the need for external components. It also offers advanced system communication and monitoring through a TFT display and wireless connectivity.
| Model | Energy Efficiency Index (EEI) | Max Head | Max Flow | Control Features |
|---|---|---|---|---|
| MAGNA3 Series (ECM Circulator) | ≤ 0.18 | 18 m (59 ft) | 73 m³/h (321 GPM) | AUTOADAPT, FLOWADAPT, FLOWLIMIT, Constant Pressure, Proportional Pressure, Constant Temperature, TFT display, wireless connectivity, BMS integration |
| MAGNA1 Series (ECM Circulator) | ≤ 0.20 | 17.37 m (57 ft) | 68.5 m³/h (302 GPM) | Proportional Pressure, Constant Pressure, Constant Curve, LED indicators, basic wireless connectivity |
Competitive Models
^PATA ESC-250
Taiko ESC-250 — centrifugal pump for engine room cooling water and general service duties, 250 m³/h capacity.
^PAGI AEB1E Series (Progressive Cavity)
^PASA EVZ-200
Shinko EVZ-200 — vertical centrifugal pump for marine cooling water, bilge, and fire service, 200 m³/h capacity.
^PAGL SM Series (Macerator Pump)
^PAGA SNH Series (Three-Screw Pump — Lube/Fuel Oil)
Send enquiry
Send an enquiry to the manufacturer of ^PAKE MAGNA3 Series (ECM Circulator). One broadcast per day.
Contribute or correct
Spotted a missing or incorrect entry? Let the maintainers know. Zulu Code is open under CC BY 4.0 — every correction strengthens the standard for the whole industry.
Code map
^P A K E │ │ │ └── Model: MAGNA3 Series (ECM Circulator) │ │ └───── Make: Grundfos │ └──────── Equipment: Centrifugal Pump └─────────── System: Pumps
