^PAKH
CHI/CHIE Series (Horizontal Booster)
Description
Zulu Code has not yet published a description for ^PAKH. Contribute one.
Did you know
- The Grundfos CHI series, a horizontal multistage centrifugal pump, was designed for pumping thin, non-explosive liquids and is made of corrosion-resistant materials. The CHIE series is a variant of the CHI, incorporating an MLE motor with a built-in PI-controller for variable speed control.
- The CHI/CHIE series sits within Grundfos's range of horizontal multistage centrifugal pumps, alongside the CM/CME series. The CM/CME series is also a horizontal multistage pump, but it is designed with a focus on compactness, potentially requiring an adapter plate for replacement of older CHI/CHIE models.
- The CHI/CHIE series is chosen for its stainless steel construction in all liquid-contacting parts, making it suitable for industrial applications requiring corrosion resistance. The CHIE model, in particular, offers variable pump performance through its integrated variable frequency drive and system controller, allowing for constant pressure applications and energy savings.
| Model | Motor Type | Speed Control | Material (wetted parts) | Max Liquid Temperature |
|---|---|---|---|---|
| CHI Series (Horizontal Booster) | Standard 1 or 3 phase | Constant Speed | Stainless Steel (AISI 316) | 230°F (110°C) |
| CHIE Series (Horizontal Booster) | MLE Motor (1 phase, 230V) | Variable Speed (integrated VFD) | Stainless Steel (AISI 316) | 230°F (110°C) |
| CM Series (Horizontal Multistage) | Mains-operated | Constant Speed | Cast iron, Stainless steel (AISI 304 or AISI 316) | 248°F (120°C) |
| CME Series (Horizontal Multistage) | Integrated frequency converter and PID controller | Variable Speed | Cast iron, Stainless steel (AISI 304 or AISI 316) | 248°F (120°C) |
| CR Series (Vertical Multistage) | Standard Grundfos motor | Constant Speed | Cast iron, Stainless steel (AISI 304 or AISI 316L), Titanium | 356°F (180°C) |
| CRE Series (Vertical Multistage) | MLE Motor (integrated VFD) | Variable Speed | Cast iron, Stainless steel (AISI 304 or AISI 316L), Titanium | 356°F (180°C) |
Competitive Models
^PASA EVZ-200
Shinko EVZ-200 — vertical centrifugal pump for marine cooling water, bilge, and fire service, 200 m³/h capacity.
^PAGE NB Series (Standardized Centrifugal, EN 733)
^PATA ESC-250
Taiko ESC-250 — centrifugal pump for engine room cooling water and general service duties, 250 m³/h capacity.
^PAGA SNH Series (Three-Screw Pump — Lube/Fuel Oil)
^PAGI AEB1E Series (Progressive Cavity)
Send enquiry
Send an enquiry to the manufacturer of ^PAKH CHI/CHIE Series (Horizontal Booster). One broadcast per day.
Contribute or correct
Spotted a missing or incorrect entry? Let the maintainers know. Zulu Code is open under CC BY 4.0 — every correction strengthens the standard for the whole industry.
Code map
^P A K H │ │ │ └── Model: CHI/CHIE Series (Horizontal Booster) │ │ └───── Make: Grundfos │ └──────── Equipment: Centrifugal Pump └─────────── System: Pumps
