Description
Zulu Code has not yet published a description for ^PAKX. Contribute one.
Did you know
- Grundfos was founded in 1945 by Poul Due Jensen in Denmark. The company initially focused on manufacturing pumps, and by 1967, the company name was changed to 'Grundfoss,' which was later adjusted to 'Grundfos' in 1968.
- The MTH Series is part of Grundfos' immersible pump offerings, designed for tank-top mounting with the pump unit submerged in the liquid. This positions it alongside other immersible pumps like the MTR, MTA, MTD, and MTS series, which also cater to various industrial applications. In contrast, the Grundfos CR series consists of vertical multistage centrifugal pumps, typically used for higher pressure applications and installed in-line, while the CM series comprises horizontal multistage pumps, known for their compact design and suitability for moderate pressure applications.
- The MTH Series is chosen for its compact design, integrating the motor and pump into a single unit for easy installation. Its immersible nature, with variable lengths, makes it ideal for applications requiring the pump to be submerged in tanks, such as machine tools, wash and clean systems, and chillers.
| Model | Max Flow Rate | Max Head | Motor Power | Liquid Temperature Range | Configuration |
|---|---|---|---|---|---|
| MTH Series (Multistage Turbine Horizontal) | 25 m³/h (417 l/min) | 100 m | 0.55-4 kW | -10 °C to +90 °C | Immersible, vertical multistage centrifugal |
| CR Series (Vertical Multistage Centrifugal) | 180 m³/h (3000 l/min) | 500 m | 0.37-75 kW | -40 °C to +180 °C | Vertical, in-line multistage centrifugal |
| CM Series (Horizontal Multistage Centrifugal) | 8.4 m³/h (140 l/min) (CM3-5 model) | 68.8 m (CM3-5 model) | 0.37-1.1 kW (CM1-4 to CM1-7 models) | -30 °C to +120 °C | Horizontal, end-suction multistage centrifugal |
Competitive Models
^PATA ESC-250
Taiko ESC-250 — centrifugal pump for engine room cooling water and general service duties, 250 m³/h capacity.
^PAGI AEB1E Series (Progressive Cavity)
^PASA EVZ-200
Shinko EVZ-200 — vertical centrifugal pump for marine cooling water, bilge, and fire service, 200 m³/h capacity.
^PAGL SM Series (Macerator Pump)
^PAGA SNH Series (Three-Screw Pump — Lube/Fuel Oil)
Send enquiry
Send an enquiry to the manufacturer of ^PAKX MTH Series (Multistage Turbine Horizontal). One broadcast per day.
Contribute or correct
Spotted a missing or incorrect entry? Let the maintainers know. Zulu Code is open under CC BY 4.0 — every correction strengthens the standard for the whole industry.
Code map
^P A K X │ │ │ └── Model: MTH Series (Multistage Turbine Horizontal) │ │ └───── Make: Grundfos │ └──────── Equipment: Centrifugal Pump └─────────── System: Pumps
